3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box

Product Categories

JINAN TRUCKMAN AUTOMOBILE CO.,LTD

Contact Now

Name: 3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box
Brand: TRUCKMAN
Price: 1 USD

Brand Name : TRUCKMAN

Model Number : TKM40CCT

Certification : SGS, BV, CTN

Place of Origin : CHINA

MOQ : 1 Units

Price : Price is negotiable

Payment Terms : L/C, T/T

Supply Ability : 1500 Units Per Month

Delivery Time : 20 working days

Packaging Details : Nude

Axles : 3 axles, FUWA brand

Support Leg : JOST brand

Brake System : WABCO Brand

Tire : 12.00R20,315/80R22.5/13R22.5

Color : Optional

Other : With Tool Box

Contact Now

-1. Main Specification For The Concrete Mixer Trailer.

-. With 4 cylinder diesel WEICHAI brand engine

-. 35-55 cubic tank box

-. Easy unloading cement

-. Use good brand spare parts, such as FUWA, LINGLONG, JOST etc

-. Tire model could optional, such as 315/80R22.5, 12.00R20, 13R22.5

Weight:	Loading Capacity	60T
Weight:	Axle Weight Load	13T
Specification	Axle number	3
	Axle Brand	FUWA
	Suspension	Common mechanical
	King Pin	2" or 3.5" traction pin
	Dimensions (LxWxH)	1300025004200mm
	Support legs	28T
	Wheel Rim	9.0-22.5
	Wheelbase	7180+1310+1310mm
	Steel Spring	10 pieces per axle
	Tank body & end	St-37/4mm steel&6mm steel sheet Shape:V type
	Engine	Diesel engine:weichai brand model:4102.44 KW
	Discharge valve & pipe	4” disc valve&4” seamless steel tube
	Air-charging system	2” main hole. 2” check valve.1.5” safe valve.0.4Mpa.gauge
	Quadratic blow	1” diameter check valve
	Discharge cover	2-4 sets of 100mm discharge valves
	Landing Gear	Manual operating, Heavy duty landing gear (Brand Optional)
	Manhole cover	500mm manhole cover 2 sets with 2 breather valve
	Accessories	1 Set standard tool box
	Light	Tail lamp with turn signal, brake light & reflector, side lamp etc.
	Painting	1coat of anti corrosive primer, twice coats of final paint
	compressor	BOHAI brand 14M3
Tire:	Tire spe.	12R22.5 Chinese brand
	Number of Tire	12 pieces
	Spare Tire Carriers	2 pieces
Frame: (specs. and materials)	Main beam	The height of the beam is 500mm;
	Main beam	Down plate is 16mm;Middle plate is 8mm. Up plate is 14mm
	Tank body	5mm steel plate, head and back head made of 6mm steel plate
	Tank body	the shape can be column or TV square shape
Brake	Brake Chamber	Six big chamber( Brand Optional )
Brake	Brake system	Dual Line Brake system (ABS )

3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box

-2. Shipment Details.

3 Axles Concrete Mixer Trailer 40 Cubic Truckman Brand With Tool Box

There have RO-RO, BULK CARGO, FRAME vessel could choose, and delivery time could guarantee.

And with different freight cost, please contact with us get more details.
